2000w / 3000w metallfiber laser skjæremaskin ac380v cypcut kontrollsystem

produkt detaljer

---

Sertifisering: CE, FDA, IOS9001
Betalings- og leveringsbetingelser:
Minimum bestillingsmengde: 1 sett
Pris: USD
Emballasjedetaljer: Standard treemballasje
Leveringstid: 30-45 dager
Betalingsbetingelser: T / T, Western Union, MoneyGram, L / C, D / P
Forsyningsevne: 100 sett per måned

Detaljert produktbeskrivelse

---

Modell:	RL-3015-2000	Laserkraft:	2000W
Laserkilde:	Max / Raycus / IPG	Maksimal behandlingsstørrelse:	3000 * 1500mm
Maksimal driftshastighet:	800 mm / s	Kontrollsystem:	Cypcut
Materiell kuttetykkelse:	0.2-30mm	Elektrisk strømforsyning:	AC380V 50Hz / 5KW
Posisjonsnøyaktighet:	± 0,05 mm / 500mm	HS kode:	8456110090
Transportpakke:	Trekartong	Vekt:	1100kg
Gjenta nøyaktighet:	± 0,05 mm / 500mm	Lasertype:	Fiberlaser

produktbeskrivelse

---

Fiber Laser Cutting Machine is used for cutting steel, aluminum, titanium, copper and other metal materials with higher laser cutting quality, speed, precision and efficiency. Now the fiber laser cutter for sale with affordable price and free fiber laser cutting system service from China professional CNC laser manufacturer.

Features of 2000W Fiber Metal Laser Cutting Machine

---

Stability and reliability of light path system and control system.Stable running: adopt top world import Fiber lasers, stable performance, key parts can reach 100,000 hours.
Very low cost, every hour only consumed 0.5W to 1.5W electricity, cutting all kinds of sheet metal by air.
Imported original fiber lasers,high and stable function,lifespan is over 100000 hours.
Higher cutting quality and efficiency ,cutting speed is up to 80m/min with appearance and beautiful cutting edge.
Imported servo motor and gearing system to guarantee precise cutting.
German high performance reducer,gear and rack;Japanese guide and ball screw.
Dedicated software enables graphic or text to instantly designed or processed. Flexible and easy operation.

Tekniske parametere

---

Laserkraft	2000W/3000/4000W/6000W
Laserkilde	MAX/Raycus/IPG
Lasertype	Fiberlaser
Laser bølgelengde	1064nm
Laser Beam Quality	<0.373mrad
Working Table	Sawtooth
Fiber Laser skjærehode	Raytool
Focus lens	Raytool
Motor&Drivers	Yaskawa servomotor produsert i Japan
redusering	France motovario
Guide skinner	High accuracy from Germany
Overfør systemet	Dual Rack & Pinion-type
Rack-system	Atlanta rack made in Germany
Kontrollsystem	Professional laser control system-Cycut
Hjelpegass for skjæring	Oxygen.Nitrogen
Kompatibel programvare	Autocad.Coreldraw.etc
Maskinens vekt	8000KG
Warranty time	Whole machine for 3 years
Bemerke	Automatic exchange worktable , cover(option)

applikasjoner

---

Applicable materials: thin sheet metal, a variety of high quality 0.5 -3mm carbon steel sheet cutting, stainless steel plate, aluminum alloy plate, galvanized sheet, electrolytic plate, silicon steel, titanium alloy, aluminium zinc plate and other metal materials.

Applicable industries: Kitchen appliance, electric control box, high-resolute device, mechanical equipment, electrical equipment, lighting, posters, auto parts, display equipment, hardware and other metal processing.
